Detention Tables
Spider Octogon Top Tables
Part No: 7420-2-X-M0 (Shown)
DDS 2-Man Spider Dayroom Tables are designed and manufactured to meet the requirements of all County, State and Federal Building Codes. All tables are assembled using domestic steel, fully welded construction and steel surfaces are Powdercoat Primer/Gray ready for finish painting by others.
Specifications:
Top/Seat material: -M0 42" x 30" x 1-1/2 11ga steel top, 12" dia x 1-1/2 14ga SSTL seats
Frame material: 4" x 4" x 1/4" steel pedestal with 3" x 3" x 3/16" tube seat arms
Mounting base: 24" x 24" x 3/8" steel
Overall size: 72" x 30" x 30" tall
Finish: -X Powdercoat Primer/Gray on all steel components, #4 Brush on SSTL Seats
Options Available:
Powder Coating: -S Powder Coated in Cardinal Standard Colors from Powder Color Brochure below - Up Charge
Stainless Top: -M5 in 304-2B Mill or -M6 304-#4 Brushed finish - Up Charge
Part No: 7420-3-X-M0 (Shown)
DDS 3-Man w/ADA Spider Dayroom Tables are designed for Wheel Chair Access and manufactured to meet the requirements of all County, State and Federal Building Codes. All tables are assembled using domestic steel, fully welded construction and steel surfaces are Powdercoat Primer/Gray ready for finish painting by others.
Specifications:
Top/Seat material: -M0 42" x 42" x 1-1/2 11ga steel top, 12" dia x 1-1/2 14ga SSTL seats
Frame material: 4" x 4" x 1/4" steel pedestal with 3" x 3" x 3/16" tube seat arms
Mounting base: 24" x 24" x 3/8" steel
Overall size: 72" x 53" x 30" tall
Finish: -X Powdercoat Primer/Gray on all steel components, #4 Brush on SSTL Seats
Options Available:
Powder Coating: -S Powder Coated in Cardinal Standard Colors from Powder Color Brochure below - Up Charge
Stainless Top: -M5 in 304-2B Mill or -M6 304-#4 Brushed finish - Up Charge
Part No: 7420-4-X-M0 (Shown)
DDS 4-Man Spider Dayroom Tables are designed and manufactured to meet the requirements of all County, State and Federal Building Codes. All tables are assembled using domestic steel, fully welded construction and steel surfaces are Powdercoat Primer/Gray ready for finish painting by others.
Specifications:
Top/Seat material: -M0 42" x 42" x 1-1/2 11ga steel top, 12" dia x 1-1/2 14ga SSTL seats
Frame material: 4" x 4" x 1/4" steel pedestal with 3" x 3" x 3/16" tube seat arms
Mounting base: 24" x 24" x 3/8" steel
Overall size: 72" x 72" x 30" tall
Finish: -X Powdercoat Primer/Gray on all steel components, #4 Brush on SSTL Seats
Options Available:
Powder Coating: -S Powder Coated in Cardinal Standard Colors from Powder Color Brochure below - Up Charge
Stainless Top: -M5 in 304-2B Mill or -M6 304-#4 Brushed finish - Up Charge
Part No: 7420-6-X-M0 (Shown)
DDS 6-Man Spider Dayroom Tables are designed and manufactured to meet the requirements of all County, State and Federal Building Codes. All tables are assembled using domestic steel, fully welded construction and steel surfaces are Powdercoat Primer/Gray ready for finish painting by others.
Specifications:
Top/Seat material: -M0 78" x 42" x 1-1/2 11ga steel top, 12" dia x 1-1/2 14ga SSTL seats
Frame material: 4" x 4" x 1/4" steel pedestal with 3" x 3" x 3/16" tube seat arms
Mounting base: 2ea. 24" x 24" x 3/8" steel
Overall size: 108" x 72" x 30" tall
Finish: -X Powdercoat Primer/Gray on all steel components, #4 Brush on SSTL Seats
Options Available:
Powder Coating: -S Powder Coated in Cardinal Standard Colors from Powder Color Brochure below - Up Charge
Stainless Top: -M5 in 304-2B Mill or -M6 304-#4 Brushed finish - Up Charge
Spider Round Top Tables
Part No: 7412-4-X-M0 (Shown)
DDS 4-Man Spider Dayroom Tables are designed and manufactured to meet the requirements of all County, State and Federal Building Codes. All tables are assembled using domestic steel, fully welded construction and steel surfaces are Powdercoat Primer/Gray ready for finish painting by others.
Specifications:
Top/Seat material: -M0 42" dia x 1-1/2 11ga steel top, 12" dia x 1-1/2 14ga SSTL seats
Frame material: 4" x 4" x 1/4" steel pedestal with 3" x 3" x 3/16" tube seat arms
Mounting base: 24" x 24" x 3/8" steel
Overall size: 72" dia. x 30" tall
Finish: -X Powdercoat Primer/Gray on all steel components, #4 Brush on SSTL Seats
Options Available:
Powder Coating: -S Powder Coated in Cardinal Standard Colors from Powder Color Brochure below - Up Charge
Stainless Top: -M5 in 304-2B Mill or -M6 304-#4 Brushed finish - Up Charge
Part No: 7412-5-X-M0 (Shown)
DDS 5-Man Spider Dayroom Tables are designed and manufactured to meet the requirements of all County, State and Federal Building Codes. All tables are assembled using domestic steel, fully welded construction and steel surfaces are Powdercoat Primer/Gray ready for finish painting by others.
Specifications:
Top/Seat material: -M0 45" dia x 1-1/2 11ga steel top,12" dia x 1-1/2 14ga SSTL seats
Frame material: 5" Sch-40 Pipe pedestal with 3" x 3" x 3/16" tube seat arms
Mounting base: 30" x 30" x 3/8" steel
Overall size: 72" x 30"
Finish: -X Powdercoat Primer/Gray all steel components, #4 Brush on SSTL Seats
Options Available:
Powder Coating: -S Powder Coated in Cardinal Standard Colors from Powder Color Brochure below - Up Charge
Stainless Top: -M5 in 304-2B Mill or -M6 304-#4 Brushed finish - Up Charge
